Pinarello

D2151272223-00001

New Grevil F7 MY26 - Force XPLR AXS - MOST Gravel Carbon 45

$7,250.00
Happy New Year 2026 — 5% off eBike accessories. Discount automatically applied in cart.
Color: Stone Turquoise
Size: 47

Pickup available at Brimstone Bicycles Shop

Usually ready in 2-4 days

The new generation of Grevil F is lighter, faster, and designed to be ridden for days on end. No matter the conditions or the duration of the race, the bike’s versatility provides the perfect solution to help you compete to win.

Components

Frame TORAY T900 UD
Fork F Onda Fork with ForkFlap™, Tapered head tube
Headset TiCR integrated
Crankset and Chainrings SRAM FORCE XPLR 1x13
Rear Derailleur SRAM FORCE XPLR AXS
Shifters SRAM FORCE AXS
Cassette SRAM Force
Chain SRAM Force
Bottom Bracket SRAM BB DUB ITALIAN 70mm ROAD WIDE
Brakes Sram Force 2 pistons caliper, 160mm rotor
Wheelset MOST Gravel Carbon 45
Tires VITTORIA TERRENO T50 45
Handlebar JAGUAR ULTRA GR TICR
Stem TIGER ALU AERO TICR
Bar Tape MOST Ultragrip evo 3mm - Black
Saddle Most Lynx My26
Seatpost D-SHAPE SEATPOST
Seat Clamp fsc frontal seat clamp
Axles NEW MOST Ultra Light Custom Axle 12x100 & 12x142, tool free removal

Geometries

CF CC L I A[°] B[°] F P T D R G WB REACH STACK
410 470 530 125.6 74.5 70.25 603.9 430 115 72 55 405 1023.5 368.4 553.2
440 500 545 137.8 74 70.5 614.5 430 130 72 55 405 1034.2 376.1 568.3
470 530 558 148.3 73.75 70.75 625.8 430 150 67 55 405 1047 383.7 583.2
490 550 570 156.2 73.5 71.75 621.9 430 160 67 50 405 1043 390.4 598.4
510 575 587 168.1 73 72 631.9 430 175 67 50 405 1053.1 398.2 613.6
545 600 607 180.4 72.5 72.25 644.3 430 195 67 50 405 1065.5 406.9 633.7
NEW GREVIL F7 SRAM FORCE XPLR AXS Geometry

CE: SEAT TUBE CENTER - END, CC: SEAT TUBE CENTER - CENTER, L: TOP TUBE CENTER - CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK
