Cinelli Pressure ADR – SRAM Rival AXS

Pressure ADR combines pure race DNA with long-distance comfort: tuned layup, refined tube profiles, and fully integrated cables for a sleek endurance aero-racer.

The Pressure ADR continues to refine the design and performance developments of our aero-racer, the Pressure fine tuning it for epic, long-distance racing. The ADR in fact maintains the signature pure competition handing and feel of the Pressure, fine-tuning tube sections and carbon fiber lay-up to make it more suitable for long hours in the saddle. These engineering considerations are complemented by fully-integrated cable routing and the use of standard seatpost and fork steerer diameters, allowing the owner to easily install world-leading after market component solutions.

Highlights

• ASSEMBLED IN THE US
• Tuned for ultimate racing comfort
• Aggressive rider position
• Integrated seatpost clamp and cable routing
• Possibility to customize build with after-market components thanks to the standard seat post and fork steerer diameters

Assembly

• Colour: All Colours
• Drivetrain: SRAM Rival AXS
• Handlebar: Cinelli Vai
• Stem: Alu 6063
• Seatpost: Cinelli Vai ø 27,3
• Shifters: SRAM Rival AXS
• Brakes: SRAM Rival AXS
• Rotors: SRAM Paceline 160 mm
• Ft. derailleur: SRAM Rival AXS
• R. derailleur: SRAM Rival AXS
• Crankset: SRAM Rival D1 DUB DM 46/33
• Cassette: SRAM Rival CS XG 1250 D1 10-36t
• Chain: SRAM Rival AXS
• Wheelset: Boyd Rouleur Alloy Disc
• Tyres: Vittoria Zaffiro Pro 700x28
• Saddle: Selle Italia Model X

Frame Specs

• Sizes: XS (45) - S (48) - M (51) - L (54) - XL (57)
• Stem: Included. XS 90mm - S 100mm - M 100mm - L 110mm - XL 110mm
• Material: Columbus Carbon Monocoque
• Headset: IS 52/28,6 | IS 52/40
• Seatpost: ø 27,2
• Seat Clamp: Hidden (included)
• BB Shell: Press Fit 86,5 x 41 mm
• Ft. derailleur: Braze-On
• Routing: Full Internal - Di2 Compatible
• Color: Sun Faded Laser Blue / Midnight Scream
• Tyre Clear.: up to 700x30 mm
• Fork: Columbus Disc 1-1/2” Carbon Monocoque Internal Cable Routing
• Weight: Frame 990g (size M) - Fork 420g (uncut)
• Brake: Flat Mount Disc Brake, Rotor Size Up To 160 mm
• Dropouts ST: Rear TA Ø 12x142mm - M12x162 / Front TA Ø 12x100mm - M12x120
• Includes: Ft.-Re. Skewers, Headset, Stem

Geometry

All measurements in millimeters unless otherwise stated.
